Holding Capacity | Spindle Supplied | Bar Opens | Handle Opens | A | B | C | D | E | F | G | H | J | K | L | M | Weight | IGS | STEP | DWG |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
770 LBS. (350kg) | GH-SF-12400 | 85° | 170° | 10.83 (275) | 0.87 (22) | 2.36 (60) | 0.35 (9) | 1.18 (30) | 1.89 (48) | 3.94 (100) | 7" (178) | 2.24 (57) | 3.03 (77) | 0.35 (9) | 0.98 (25) | 3.51 LBS. (1,590 g) | Download | Download | Download |
-
